MY5-F Series Professional 18W RGB Laser Light with FB4 Controller
MIYA MY5-F is a high-power 18W RGB laser projector with built-in FB4, designed for professional outdoor use. With IP65 waterproof housing, ultra-sharp <1mrad beams, and precise analog color modulation, it delivers stunning, reliable performance for large-scale shows and permanent installations.
Learn more
Product specification
Showcase specifications about a product to help your customers making an informed decision about their purchase.
RGB 20W
35-40 KPPS high-speed scanning
AC110/220V, 50–60Hz ±10%
ILDA / DMX512 / Auto / Master–Slave
Analog modulation
Max 350W
30 KPPS high-speed scanning
red 638±5nm, green 520±5 nm, blue 455±5nm
Imported semiconductor solid-state laser
<1.2 mrad
<8*6 mm
international standard ILDA control/DMX512 signal control/self-walk/master-slave
RJ45 ILDA / DMX512, compatible with Pangolin, Tiger, Pearl, MA controllers
One-beam protection, auto shutoff when signal lost
IP66
Indoor/Outdoor
Video
PRODUCT DETAILS/FEATURES
Product Advantages
Product Overview
Scene Display
FAQ
Q1: Does the SF5-F Series support wireless control or software integration?
A: Yes, the MY5-F Series comes with a built-in FB4 control system, allowing direct connection via Ethernet to software like Pangolin QuickShow and BEYOND. This makes it easy to program, schedule, and control your laser shows without extra hardware.
Q2: Is the projector suitable for outdoor use?
A: Absolutely. The MY5-F Series is IP65-rated, meaning it’s fully sealed and weather-resistant. It’s designed for outdoor laser shows, festivals, architectural lighting, and permanent installations—even in rain or dusty environments.
Q3: What types of control modes are supported?
A: The MY5-F Series supports multiple control options: ILDA, DMX512, auto-run, and master-slave modes. It offers full flexibility whether you’re running a synced stage setup or standalone operation.
Q4: How safe is this laser for professional use?
A: Safety is built in. The MY5-F Series includes single-beam protection, blackout on signal loss, and secure startup with a key lock. It meets international laser safety standards—ideal for professional and public-facing laser displays.
